Product Details
- Place of Origin: Zhe Jiang Ning Bo
- Brand Name: mould
- Model Number: HMG-A
| Item | Unit | HMG-60BA1 | HMG-100A | HMG-160A | HMG-200A | HMG-300A | HMG-350A | HMG-400A | HMG-500A | HMG-600A |
| Clamping force | T | 60 | 100 | 160 | 200 | 300 | 350 | 400 | 500 | 600 |
| Opening force | T | 18 | 26 | 40 | 46 | 56 | 70 | 100 | 150 | 160 |
| Overturn force | T | 1.3 | 4 | 8 | 10 | 15 | 18 | 20 | 32 | 40 |
| Ejecting force | T | 3 | 3 | 7 | 7 | 10 | 10 | 10 | 12 | 12 |
| Mold dimension | mm | 900x600 | 1400x1100 | 1600x1300 | 1800x1500 | 2000x1700 | 2600x1800 | 3000x2000 | 3100x2100 | 4000×2500 |
| Opening stroke of upper and lower mold | mm | 850 | 1500 | 1700 | 1900 | 2000 | 2200 | 2500 | 3000 | 3200 |
| Shift-out stroke of mold | mm | 1450 | 2150 | 2550 | 3150 | 3350 | 3540 | 4325 | 4800 | 6000 |
| Ejection stroke | mm | 220 | 220 | 250 | 250 | 250 | 250 | 250 | 300 | 300 |
| Overturn angle | ° | 180 | 180 | 180 | 180 | 180 | 180 | 180 | 180 | 180 |
| Max weight of mold | T | 3 | 8 | 16 | 20 | 30 | 40 | 45 | 60 | 80 |
| External dimension | mm | 2500x1620x3700 | 4000x2200x4500 | 5000x2500x5200 | 5900x2800x5500 | 6200x2960x5850 | 5820x3800x7700 | 7050x4200x8700 | 7200x4350x8700 | 9600×5200×9000 |
| Machine weight | T | around6 | around12 | around18 | around22 | around33 | around50 | around80 | around96 | around130 |
- Place of Origin: Zhe Jiang Ning Bo
- Brand Name: mould
- Model Number: HMG-A
